DELCO Pneumatic Actuated 4 Way Flange Ball Valves-DK66-4TF
The Pneumatic Actuated 4 Way Flange Ball Valves are precision-engineered components designed for fluid control applications requiring intricate directional adjustments. Featuring a 4-way flange design, these valves offer unparalleled versatility in regulating fluid flow along four distinct pathways. Equipped with pneumatic actuators, they ensure efficient and precise operation, allowing for rapid response times and accurate fluid control.
The Pneumatic Actuated 4 Way Flange Ball Valves adopts the integrated structure, which is beautiful in shape, light and pleasant, quick in disassembly and assembly, flexible in operation, excellent in performance, simple in matching and large in circulation capacity. It is widely used in the industrial automation system of food, environmental protection, light industry, petroleum, paper making, chemical industry, electric power and other industries
Model: Pneumatic flange Ball Valves
Size Range: 1″ to 6″
Pressure Range: 1.6 to 6.4MPa
Material: Stainless Steel 304/316
What Is The 4 Way Flange Ball Valve?
4-way flange ball valves are precision-engineered components utilized in fluid control systems to regulate the flow of fluids along four distinct pathways. Unlike traditional ball valves that typically offer two-way or three-way flow control, 4-way flange ball valves provide enhanced versatility by allowing fluid to be directed in four different directions. This advanced design enables more intricate fluid distribution patterns, making them ideal for applications requiring complex flow configurations.
Equipped with flange connections, these valves ensure secure and leak-free installation, minimizing the risk of fluid leakage and contamination. They are commonly used in various industries, including chemical processing, oil and gas, water treatment, and HVAC systems, where precise fluid control is essential for optimal system performance. In summary, 4-way flange ball valves are sophisticated components designed to provide precise and versatile fluid control solutions in industrial applications.
Benefits Of 4 Way flange Ball Valves
The Pneumatic Actuated 4 Way Flange Ball Valves offer a multitude of advantages that distinguish them as superior components in fluid control systems. Their foremost benefit lies in enhanced versatility, thanks to the four distinct pathways they provide for fluid flow regulation. This versatility enables precise management of complex flow patterns, allowing for optimized fluid distribution in diverse industrial settings.
Additionally, equipped with pneumatic actuators, these valves ensure efficient and reliable operation, with rapid response times and precise fluid control.
Constructed from high-quality materials, they exhibit exceptional durability and reliability, capable of withstanding harsh operating conditions for prolonged service life. Moreover, the inclusion of flange connections streamlines the installation process, reducing labor costs and minimizing downtime during system assembly. Overall, the Pneumatic Actuated 4 Way Flange Ball Valves offer unparalleled flexibility, efficiency, and reliability, making them indispensable components in modern fluid control systems.
4 Way Flange Ball Valves technical Parameter:
Body | Size range | Body material | End connection | Operating pressure | Structure |
DN25~DN150 | SS304, SS316, SS316L | Flange | PN1.6MPa~6.4Mpa | Floating ball core | |
Valve components | Sealing material | Core material | Stem material | Applicable media | |
PTFE, PPL | Stainless steel | Stainless steel | Water, air, oil, gas, etc |
Features Of 4 Way Flange Ball Valves
The features of 4-way flange ball valves encompass their sophisticated design and functionality tailored for precise fluid control:
Four-Way Flow Control: Unlike conventional ball valves, 4-way flange ball valves provide four distinct pathways for fluid flow regulation, offering enhanced versatility in managing complex flow patterns and distribution.
Robust Construction: Constructed from high-quality materials, these valves exhibit exceptional durability and reliability, ensuring long-term performance even in harsh operating conditions.
Flange Connections: Equipped with flange connections, these valves offer secure and leak-free installation, minimizing the risk of fluid leakage and contamination, while also simplifying the installation process.
Pneumatic Actuation: Many 4-way flange ball valves come with pneumatic actuators, enabling efficient and precise operation, rapid response times, and accurate fluid control, enhancing overall system performance.
Wide Application: With their ability to handle intricate flow configurations, these valves find applications across various industries, including chemical processing, oil and gas, water treatment, and HVAC systems, where precise fluid control is crucial.
In summary, the features of 4-way flange ball valves highlight their advanced design, robust construction, precise operation, and versatility, making them indispensable components in fluid control systems across diverse industrial applications.
Technical Parameters of Valves Actuator
Air source processor: The pneumatic triplet, a vital accessory for pneumatic valves, combines filtering, pressure reduction, and lubrication functions. The pressure reducing valve adjusts inlet pressure to a stable outlet pressure, utilizing the medium’s energy. In two-piece assemblies, it couples with a filter for compressed instrument air filtering. In three-piece configurations, it adds lubrication to the air, ensuring efficient operation.
Pneumatic solenoid valve: The pneumatic solenoid valve, also known as a directional control valve, is a vital component for regulating the opening and closing of pneumatic valves. It functions by magnetizing and demagnetizing, which directs the gas flow based on voltage signals. Commonly employed to manage gas source and circuit flow, these valves offer precise control over valve operations through voltage signals.
Limit switch: The valve limit switch, also called a travel switch, is a critical field instrument in automatic control systems. It detects the valve’s status and outputs signals for open or closed positions. This switch is essential for confirming and executing subsequent programs by programmers. Additionally, it serves as a vital component for valve interlock protection and remote alarm indication within the system. It effectively indicates and provides feedback on mechanical equipment’s movement limit position.
Valve positioner: The valve positioner is a crucial component of pneumatic control valves, enabling precise control over valve positioning. It utilizes the valve stem displacement signal as input feedback and the controller output signal as the control signal. By comparing these signals, any deviation triggers adjustments to the actuator output signal, ensuring a direct correspondence between valve stem displacement and controller output.
Manual device: The manual device is an essential component that complements the pneumatic actuator assembly. It serves to facilitate manual or pneumatic operation for butterfly valves and ball valves with a 90° opening. This mechanism is crucial for ensuring versatility and flexibility in valve operation, allowing for both manual and automated control as needed.
