DELCO 4 Way Flange Motorized Ball Valves-DK55-4TF
This motorized 4-way flange ball valve serves as a pivotal component for interrupting or establishing the flow of media within pipelines. Not only does it provide the essential function of fluid regulation and control through the utilization of a quarter-turn electric actuator, but it also incorporates a manual override feature.
With a torque range spanning from 50Nm (442 in-lb) to 4000Nm (35398 in-lb), it ensures versatile and reliable operation across various applications.
Model: DK55-4TF
Size Range: 1” to 6”
Pressure Range: 1.0MPa to 6.4MPa
Material: Stainless Steel 304/316
What Is Electric 4 Way Flange Ball Valve?
An Electric 4 Way Flange Ball Valve is a sophisticated control device designed to manage the flow of fluids in pipelines efficiently. Unlike traditional valves, which are manually operated, this valve is equipped with an electric actuator, allowing for remote and automated control. The “4 way” designation signifies that the valve has four ports or openings, enabling complex flow configurations such as diversion, mixing, or distribution of the fluid.
In industrial applications, these valves are invaluable for their versatility and precision. They can be used in systems where precise control over the direction and flow rate of fluids is essential, such as in chemical processing plants, water treatment facilities, or HVAC systems. The integration of flange connections further enhances their adaptability, allowing for easy installation and maintenance in various pipeline systems. Overall, the Electric 4 Way Flange Ball Valve represents a fusion of advanced technology and practical utility, offering efficient fluid control solutions for a wide range of industrial processes.
Data Sheet of Valve:
ON/OFF Type | Feedback: the active contact signal, passive contact signal, resistance, 4-20mA |
Regulation Type | Input & Output signal: DC 4-20mA, DC 0-10V, DC 1-5V |
Field operation | The Field, Remote Control Switch Regulation and MODBUS, PROFIBUS Field Bus |
Voltage Optional | AC110-240V 380V 50/60HZ: DC12V, DC24V, Special Voltage Can be Customized |
Protection Class | IP65, Explosion Proof Construction Are Available: EX ll BT4 |
Valve Body | Valve components | ||
Size Range | DN15-DN150 | Sealing material | PTFE: -20℃~180℃ |
PPL: -29℃~250℃ | |||
Body Material | Stainless Steel | Core Material | Stainless Steel |
End Connection | ANSI Flange | Stem Material | Stainless Steel |
Operating Pressure | 1.0 / 1.6 / 2.0 / 6.4 MPa (10 / 16 / 20 / 64 bar) | Applicable media | Water, Air, Gas, Oil, Liquid |
Structure | L-port/T-port |
DELCO Electric 4 Way Flange Ball Valve
- Designed exclusively for enduring automation. Ideal for high-cycle OEM and end user applications
- Designed for compatibility with the widest variety of industrial and OEM applications.
- Designed for reparability. Wear components can be quickly and easily replaced.
- Application: Industrial Emissions Control Instrumentation Gaseous or Liquid Service
- Premium Quality/Low Cost/Made in China
Electric Actuator:
ON/OFF Type Electric Actuator: Featuring a 90-degree rotation, this actuator offers AC/DC power supply, signal control, and manual override capabilities. With high torque of up to 4000Nm, it ensures reliable performance in demanding environments.
Modulating Type Electric Actuator: Adjust the open/close angle smoothly from 0 to 90 degrees with this actuator. Equipped with AC/DC power supply, signal control, and manual override, it delivers precise control and high torque of up to 4000Nm.
Intelligent Type Electric Actuator: Take control with ease using the intelligent actuator, allowing you to adjust the open/close angle with precision. Featuring an LED display screen for convenient monitoring, it offers AC/DC power supply, signal control, manual override, and high torque of up to 4000Nm.”
Product Model: | DK55-4TF | Housing Material: | Aluminum alloy |
Waterproof Level: | IP67 | Motor power supply: | 24/110/220/380V AC±10%,24/110/220VDC 50/60HZ±10% |
Motor: | Squirrel cage asynchronous motor | Itinerary: | 90°-270±10° (above 90° in advance) |
Fail-safe: | Built-in thermal protection on: 120°C±5°C | Operating Temperature: | 97℃±15℃ |
Indicator: | Continuous position indication | Manual operation: | Mechanical handles |
Self-locking device: | The turbine and worm mechanism provide self-locking | Mechanical Limit: | 2 external adjustments |
Terminal Holes: | M18 | Ambient Temperature: | -20℃-70℃ |
Lubrication: | Aluminum-based grease EP type | Material: | Steel, aluminum alloy, aluminum bronze, polycarbonate |
Ambient Humidity: | Up to 90% | Ingress Protection: | IP65; IP67; IP68 |
Explosion-proof grade: | Exd II BT4; Exd II CT6 | Ambient Temperature: | -25℃-55℃ |
Ambient Humidity: | 10~90%RH | Seismic Performance: | X Y Z 10 grams, 0.2-34HZ 30 minutes |
Coating: | Dry powder, epoxy polyester | Manufacturing Standards: | GB/JB/HG/HG/ANSI/API/JIS/DIN/OTHER STANDARDS CUSTOMIZED |
